SRS-750X200
SRS-750 provides full stroke force of 8,700 N (1,960 lbf) and is available in 7 stroke lengths.
The available flanges are Lower Square Flange (FFC-1500), Circular Flange (FC-1500), Upper Square Flange (FCS-1500), and Bottom Mounting Flange (MP-1500).
Diagram / specifications section
Preview
| L | Minimum Length (in) | 12.2 |
| S | Stroke Length (in) | 7.87 |
| Y | Total Length (in) | 20.08 |
Item specifications
- End Force At Full Stroke (LBF)2700
- Force Increase By Temperature Percent Per (°F)0.17
- Gas Volume (CuF)0.0236
- Initial Force at max. pressure (lbf) 1665
- Max Charging Pressure (Psi)2175
- Max Piston Rod Velocity (FtMin)314.96
- Max. Operating Temperature (F)176
- Min Charging Pressure (PSI)362
- Min. Operating Temperature (F)32
- Recommended Max Strokes Per MinuteSee separate file in Documents -> Brochures
- Weight (lb)15.73
