NP-750X200
NP-750 provides full stroke force between 12,000 N (2,700 lbf) and 12,100 N (2,720 lbf) and is available in 12 stroke lengths.
Diagram / specifications section
Preview
| L | Minimum Length (in) | 11.61 |
| S | Stroke Length (in) | 7.87 |
| Y | Total Length (in) | 19.49 |
Item specifications
- End Force At Full Stroke (LBF)2720
- Force Increase By Temperature Percent Per (°F)0.17
- Gas Volume (CuF)0.009181813
- Initial Force at max. pressure (lbf) 1665
- Max Charging Pressure (Psi)2175
- Max Piston Rod Velocity (FtMin)314.96
- Max. Operating Temperature (F)176
- Min Charging Pressure (PSI)362
- Min. Operating Temperature (F)32
- Recommended Max Strokes Per Minute~15-40
- Weight (lb)6.776
